AOOSTAR TA95X3D 9955X3D

Base Frequency: 2.4 GHz (slightly lower than the non-3D Ryzen 9 9955HX to accommodate additional cache power demands).

Max Boost Frequency: Up to 5.2 GHz (single-core/multi-core boost; limited by thermal headroom, optimized for cache-sensitive tasks rather than pure clock speed).

L1 Cache: 1280 KB total (80 KB per core: 32 KB L1 Instruction Cache + 48 KB L1 Data Cache), same as the non-3D 9955HX.

L2 Cache: 16 MB total (1 MB per core), dedicated to each core for low-latency access to frequently used data.

L3 Cache: 128 MB total—combines a 64 MB “base” shared L3 cache with an additional 64 MB 3D V-Cache (stacked vertically on the CPU die via TSVs, Through-Silicon Vias). This doubles the L3 cache capacity of the standard 9955HX, reducing reliance on system memory and boosting performance in games, simulations, and creative software.

The motherboard’s power delivery zone is fully covered byfull-size thermal armor. Built-in premium thermal pads seam-lessly adhere to MOSFETs for efficient heat dissipation. Addi-tionally equipped with metal SSD cooling armor, this dual-layerprotection ensures rock-solid data transmission stability andsustained performance without compromise!

Innovatively featuring a VC heat spreader covering the processor, it rapidly dissipates heat across a large surface area, in-stantly distributing core heat evenly throughout the entire heatspreader. Whether paired with tower coolers or liquid coolingsystems, it rapidly lowers core temperatures, eliminating throttling and stuttering. Even at full performance, it stays cool asever!

Supports dual-channel desktop DDR5-5600 high-frequencymemory, featuring metal anti-interference memory slots. En-ables EXPO 6000MHz overclocking potential with optimizedrouting to reduce latency.Experience seamless multitaskingand instant loading of large software applications for a comprehensive efficiency boost! PS:Actual overclocking spemayvary based on individual memory modules.

2 PCle 5.0 x4 M.2 slots deliver theoretical bandwidth up to16GB/s, loading massive games and high-definition assets inseconds. Dual-slot design meets high-speed storage andsystem partition needs! (Backward compatible)

When paired with a high-end graphics card, it can reduce the loss of the graphics card’s performance.

Featuring a 10-phase power delivery system (8+1+1),the MP2845AGQK controller chip enables unlockedRyzen 9 performance beyond its class, delivering an ex-ceptional performance experience through ultra-redun-dant design.
